PHYSICAL DIMENSIONS:

• 21.9” H x 13.2” W x 9.23” D (555 mm H x 335 mm W x 235 mm D)
• Weight - 11bs (5kg)

APPLICATION:

• Veterinary patients

POWER:

• Power Source - External AC power or internal battery
• AC Power - 100-240VAC, 50/60Hz, <150VA
• Battery - Rechargeable Lead-Acid; Operating time under the normal condition (1 hour)
• Operating time after the first alarm of low battery (10 min.)

ENVIRONMENTAL:

• Working Temperature: 5-40 C
• Storage Temperature: 0-65 C
• Working Humidity: 30-75%
• Storage Temeprature: ≤80%
• Operating Altitude: Up to 5,000 meters
• Hyperbaric Pressure - Up to 405.3 kPa

PERFORMANCE SPECIFICATIONS:

• Display - 12.1” color TFT, Touch Screen
• Resolution - 800 x 600 pixels
• Trace - 4, 6 or 8 waveforms ECG (I, II, III, aVR, aVL, aVF, V1-V6), PLETH, RESP, IBPx2, ETCO2
• Indicator - Alarm indicator; Power indicator QRS beep and alarm sound
• Trend Time - 72 hours
• Recorder - Built-in, thermal array, 2 channels
• Record - Width 48mm
• Recorder - Paper 50mm
• Record - Speed 25mm/s, 50mm/s
• OxyCRG - Combines HR, SpO2, and resp. trends into a single graph ECG
• Input - 5-lead ECG cable and standard AAMI line for connection
• Lead Choice - I, II, III, aVR, aVF, aVL, V
• Gain Choice - x0.125, x0.25, x0.5, x1.0, x2.0

FILTER:

• Diagnostic mode - 0.05 – 100Hz
• Monitoring mode - 0.05 – 75Hz
• Surgical mode - 1 – 20Hz
• Frequency Characteristic - 0.05-40 Hz
• ECG Waveforms - 7 channels
• Penetration Voltage - 4000VAC 50/60Hz
• Sweep Speed - 12.5, 25 and 50 mm/s
• HR Display Range - 30-300bpm
• Accuracy - 1% or 1bpm, whichever is greater
• S-7 Segment Detection - 7 channels
• Measurement Range - -2.0mv – +2.0mv
• Arrhythmia Analysis - 13 types
• Alarm Limit Range Setting - Upper limit 80-400bpm; Lower limit 20-150bpm

RESP:

• Measure Method - RA-LL impedance
• Range - 0-120 rpm
• Accuracy - + 3 rpm
• Alarm Upper-lower Limit Setting - Upper limit 6-120 rpm, Lower limit 3-120 rpm
• Sweep Speed - 12.5 and 25 mm/s

NIBP:

• Measuring Technology - Automatic oscillating measurement
• Cuff Inflating - <30s (0 – 300mmHg, standard adult cuff
• Measuring Period - AVE<40s
• Mode - Manual, Auto, STAT
• Measuring Interval in AUTO Mode - 2 min-4 hrs
• Pulse Rate Range - 30-250 (bpm)
• Measuring Range - Adult/Pediatric Mode, SYS 40-250 (mmHg), DIA 15-200 (mmHg); Neonatal Mode, SYS 40-135 (mmHg), DIA 15-100 (mmHg)
• Resolution - 1mmHg
• Accuracy - Pressure, Maximum Mean error 5mmHg, Max. Standard deviation 8mmHg
• Overpressure Protection - Adult Mode 280(mmHg), Neonatal Mode 150 (mmHg)
• Alarm Limit Setting - SYS 50-240 mmHg, DIA 15-180 mmHg

TEMP:

• Range - 0 – 50 C (32 – 122 F)
• Accuracy - Without sensor
• Display Resolution - 0.1 C
• Alarm Upper-lower Limit Setting - Upper limit 0-50 C, Lower limit 0-50 C
• Channel - 2 channels, provide T1, T2, ΔT
• Alarm Limit Setting - 10-50 C

MASIMO SET SPO2:

• Measuring Range:
  • SpO2: 1~100 %
  • PR: 25~20 %
• SpO2 Accuracy (non-motion):
  • Adult Pediatric: 70~69%: unspecified
  • Neonate: 70~69 %: unspecified
• SpO2 Accuracy (motion):
  • Adult Pediatric: 70~69% : unspecified
  • Neonate: 70~69 % : unspecified
• PR Accuracy (non-motion):
  • Adult Pediatric Neonate: 25?240 bpm: ±3 bpm
• PR Accuracy (motion):
  • Adult Pediatric Neonate: 25<span 20.8px;"="">~240 bpm: ±5 bpm
• Low Perfusion Performance: >0.02 % Pulse Amplitude and % Transmission >5
  • SpO2: ±2 %
  • PR: ±3 bpm
• Modes:
  • Averaging mode: 2,4,8,10,12,14 and 16 s
  • Sensitivity: Normal, APOD and Maximum

IBP (OPTION):

• Measurement Range - -10-300mmHg
• Channel - 2 channels
• Pressure Transducer Sensitivity, 5μV/V/mmHg
• Impedance Range - 300-3000Ω
• Transducer Sites - ART, PA, CVP, RAP, LAP, ICP
• Resolution - 1mmHg
• Accuracy - 1mmHg or 2%, whichever is greater
• Alarm range - -10-300mmHg

ETCO2 (OPTION) (RESPIRONICS):

• Mode of Sampling - Sidestream
• Principle of Operation -Non-dispersive infrared (NDIR) single beam optics, dual wavelength, no moving parts
• CO2 Measurement Range - 0 to 150 mmHg (0 to 19.7%, 0 to 20 kPa)
• CO2 Calculation Method - BTPS (Body Temperature Pressure Saturated)
• CO2 Resolution - 0.1mmHg(0-69mmHg); 0.25mmHg(70-150mmHg)
• CO2 Accuracy - 0-40 mmHg 2 mmHg; 41-70 mmHg 5% of reading; 71-100 mmHg 8% of reading; 101-150 mmHg 10% of reading; Above 80 breath per minute 12% of reading
• Sampling Rate - 100Hz
• Respiration Rate - 2-150 bpm
• Respiration Rate Accuracy - 1 breath
• Response Time - <3 seconds - includes transport time and rise time
• Inspired CO2 Measurement Range - 3-50 mmHg
